The Innovative software and hardware making it the ideal system for both clinical MER and for advanced clinical research

Key Features

The Neuro Omega With implemented innovative software is ideal for both clinical MER (Micro electrode recording) and for advanced clinical research applications.  MER users have full experimental control while benefiting from Alpha Omega’s highest performance, quality and clinical efficacy.

  • Expandable up to 122 channels
  • HaGuide -Real Time Subthalamic Nucleus Navigation
  • Online data streaming to MATLAB and C++
  • Closed loop stimulation control through MATLAB and C++
  • Unparalleled stimulation capabilities including conditional stimulation, programmable stimulation, and arbitrary wave definition
  • Connectivity to DBS lead with integrated LFP acquisition and stimulation tools to support Lead Confirmation*
  • Multi-source, multi-polar stimulation allows for 3D stimulation control
  • Single cable exiting the sterile field for electrode positioning, recording and stimulation
  • Online statistics including evoked potentials
  • Unique dual screen display and customizable workspace
  • Integrated analog and digital inputs and outputs



Disclaimer: This page may include information about products that may not be available in your region or country. Please consult the approved indications for use. Content on specific Alpha Omega products is not intended for users in markets that do not have authorization for use.

Want to hear more about Neuro Omega?

Fill up your details and we will get back to you within 4 business days

Error
Order now
  • Trajectory view with pattern recognition for increased neural activity electrode types
  • Flexible stimulation current ranges for microelectrode test stimulations, peripheral nerve stimulation and other stimulation research requirements
  • Complete stimulation control on the basic stimulation parameters and the ability to create unique waveforms
  • Save data for post-case analysis in MATLAB orother formats

Software Filter

Micro Channel Contact:

SPK :

High Pass Range: 0 – 600Hz

Low Pass Range: 5000 – 9000Hz



LFP:

High Pass Range: 0 – 45Hz

Low Pass Range: 200 – 400Hz



Macro Channel Contact:

LFP:

High Pass Range: 2 – 45Hz

¾Low Pass Range: 200 – 400Hz



Hardware filtering

Micro Channel Contact:

High Pass Range: 0.07 Hz

Low Pass Range: 10,000Hz

Macro Channel Contact:

High Pass Range: 0.07 Hz

Low Pass Range: 10,000Hz

Main Unit  Ports

Ethernet ports (1 GB)

1 Remote port (USB)

2 Audio out (3.5mm stereo)

Connecting external systems

Matlab

External digital or analog input or output systems





Embedded computer

Touch screen PC





Input power

100V–240V, 50Hz–60Hz





Neuro Omega Matlab Programming Package

Neuro Omega offers the capability for online bidirectional streaming between Neuro Omega and external computer through MATLAB or C++

  • Onsite Neuro Omega-Matlab tool functions training
  • Detailed Neuro Omega-Matlab tool manual
  • Sample Matlab programs created by Alpha Omega with complete syntax, description, and an example of each Matlab function to help you reduce the development time
  • MEX file for a seamless connection between Neuro Omega system and Matlab computer
  • Ethernet Isolator, allowing connection of external computer without breaking patient isolation
  • 15 hours Support package (over Phone/Skype) by Alpha Omega senior support engineer.

The Neuro Omega  - Matlab tool software functions:

  • Connects Matlab computer to Neuro Omega system
  • Online access to Neuro Omega data through Ethernet streaming
  • Flexible data saving modes controlled by Matlab
  • Programmable stimulation wave forms (digital and analog patterns)
  • Programmable Control of stimulation paradigms
  • Online control of digital ports (Inputs/Outputs) allowing to send digital TTL pulses and get digital TTL pulses or bit-words.
  • Sample Matlab programs created by Alpha Omega with complete syntax, description, and an example of each Matlab function to help you reduce the development time

Neuro Omega - NeuroFortis™

Autoclavable Drive Headstage

Automatic, motorized drive HeadStage with built-in Amplifier, Digitizer and Stimulator.

Washable, autoclavable drive HeadStage with built-in Amplifier, Digitizer and Stimulator
